JPW-HSCSAFHigh Speed Collar Type Servo Auger Filler Machine
Collar-type servo auger filler for all free-flowing and non-free-flowing powders, from 10 gm sachets to 10 kg bags.
- Range
- 10 gm – 100 gm +
- Speed
- 45–50 PPM for 10 gm – 200 gm
JPW-CMHWF
10 / 14 Head Collar Type Multi Head Weigh Filler Machine
The Joypac JPW-CMHWF 10/14-head weigh filler packs 10 gm to 10 kg at 50–60 PPM using a load-cell weigh system with ±0.5% filling accuracy.
Overview
Load-cell multi-head weigher for snacks and irregular granules — the highest accuracy option for chips and namkeen.
Suitable products
Chips and namkeen
Whole spices
Dry fruits
Pulses, dals and sugar
Sooji and all kinds of granules
Packing range
- 10 gm – 100 gm
- 200 gm – 1 kg
- 1 kg – 5 kg
- 5 kg – 10 kg
Speed
- 50–60 PPM for 10 gm – 100 gm
- 40–45 PPM for 200 gm – 1 kg
- 15–25 PPM for 1 kg – 5 kg
- 5–12 PPM for 5 kg – 10 kg
Technical specifications — JPW-CMHWF
| Specification | Detail |
|---|---|
| Packing Range | 10 gm to 10 kg (four configurations) |
| Packing Speed | 50–60 PPM (10–100 gm), 40–45 PPM (200 gm–1 kg), 15–25 PPM (1–5 kg), 5–12 PPM (5–10 kg) |
| Sealing Type | Centre seal / Side seal |
| Filling System | Load cell weigh system |
| No. of Heads | 10 or 14 heads |
| Pulling Mechanism | Belt driven servo / AC motors |
| Filling Accuracy | ±0.5% |
| Packaging Material | Heat sealable laminated roll |
| Sealing System | Pneumatic / servo |
| Machine Body | SS / MS powder coated |
| Product Contact Parts | SS-304 / SS-316 |
| Power | 5 KW, 440 V, 3 phase, 50 Hz |
| Control System | PLC controlled |
| Temperature Control | PID (through PLC) |
| Unwinding System | AC motor |
| Compressed Air | 8–12 CFM @ 6–8 kg bar |
| Dimensions (W×D×H) | 1550 × 2400 × 3650 mm (approx.) |
| Machine Weight | 2000–2500 kg |
JPW-CMHWF — frequently asked questions
- Which machine is best for packing chips and namkeen?
- The JPW-CMHWF 10/14-head multi-head weigh filler. Load-cell weighing handles light, irregular snack pieces gently at 50–60 PPM.
- Should I choose 10 heads or 14 heads?
- 10 heads suit mixed pack sizes up to 1 kg; 14 heads give higher speed and better accuracy on small snack packs and multi-SKU lines.
- Can nitrogen flushing be added?
- Yes, nitrogen flushing is available as an optional accessory for snack shelf-life extension.
Compare alternativesJPW-HSCSAF
JPW-HSCCF
JPW-SPCCF
Other Joypac machines to consider
JPW-HSCSAFJPW-HSCCFHigh Speed Collar Type Cup Filler Machine
High-output volumetric cup filler for granular groceries — dal, rice, sugar, salt, tea and detergent powders up to 5 kg.
- Range
- 10 gm – 100 gm +
- Speed
- 55–60 PPM for 10 gm – 100 gm
JPW-SPCCFChute Type Cup Filler Machine (Semi-Pneumatic)
Compact, cost-effective semi-pneumatic chute-type cup filler — an ideal entry point for small and mid-size packers.
- Range
- 10 gm – 100 gm +
- Speed
- 25–30 pouches per minute
